FU-500 solder feed unit

Accurate solder feeding

FU-500 features a compact drive unit that allows the solder feed unit to be brought closer to the iron. This adaptation makes it possible to increase the repeat accuracy of amount of solder feeding.

Equipped with countermeasures against solder ball scattering as standard

As countermeasure against scatter of flux and solder balls, the unit is equipped with a mechanism that perforates into the solder wire as standard. It is also possible to change acceptable solder wire diameter by simply replacing the pulley unit.

Supports solder diameters of 0.3 mm and up

As the unit is capable of handling extremely small solder diameter of 0.3 mm, it can be used for delicate soldering jobs.

Supported solder diameter 0.3 mm to 1.6 mm.

High-performance programming

100 programs each configurable for "Point soldering" and "Drag soldering" at low price.
Programs can be edited by PC via a USB connection.

Easy adjustment of solder feeding position

Adjustment of the position of solder feeding to the tip is critical for auto-soldering systems. FU-500 lets you adjust the solder feeding position just by turning an adjustment screw with a wrench.

Solder feed error detection

With an optical sensor for solder movement, FU-500 can detect solder clogging, slipping and the end of the roll.

Replacement Parts

	Part No.	Name	Specifications
	CX1010	Feeder unit L type	For 0.3mm to 1.6 mm dia.
	CX5006	Feeder unit straight type	For 0.3mm to 1.6mm dia.

	BX1035	Feeder cable 3m	For FU-500
	BX1036	Feeder cable 5m	For FU-500
	BX1037	Feeder cable 8m	For FU-500

	BX1076	Solder feed pulley unit (Separable)	0.3 mm   For HU-200 and FU-500
	BX1077	Solder feed pulley unit (Separable)	0.5 mm   For HU-200 and FU-500
	BX1078	Solder feed pulley unit (Separable)	0.6 mm   For HU-200 and FU-500
	BX1079	Solder feed pulley unit (Separable)	0.8 mm   For HU-200 and FU-500
	BX1080	Solder feed pulley unit (Separable)	1.0 mm   For HU-200 and FU-500
	BX1081	Solder feed pulley unit (Separable)	1.2 mm   For HU-200 and FU-500
	BX1082	Solder feed pulley unit (Separable)	1.6 mm   For HU-200 and FU-500
